Steering system
The steering oil tank assembly (Part No. 3410010-KS110) is tailor-made as an OEM-standard replacement for Dongfeng KR series commercial vehicles, including heavy-duty trucks and logistics carriers. It perfectly matches the vehicle’s original steering system mounting positions, oil inlet/outlet interfaces (thread specification: M18×1.5), and dimensional parameters (capacity: 1.8L, length×width×height: 220mm×160mm×190mm). This ensures seamless integration with the steering pump and hydraulic lines, eliminating the need for bracket modifications or interface adapters, and maintaining consistent hydraulic pressure transmission with the original system
Product Attributes
Warranty: 1 YEARS ,Part name: Steering oil tank assembly 3410010-KS110
PRODUCT DESCRIPTION
Integrated Oil Storage & Filtration Structure
The assembly features a 2-in-1 design combining the oil storage tank and a built-in high-efficiency filter element (filter precision: 25μm). The filter is strategically positioned at the oil outlet to capture impurities (e.g., metal shavings, dust) in the steering oil before it enters the steering pump, preventing abrasion of internal components like the pump rotor and valve body. Additionally, the tank is equipped with a floating oil level sensor that connects to the vehicle’s instrument panel, providing real-time low-oil-level alerts to avoid pump damage due to oil shortage
High-Durability & Corrosion-Resistant Materials
The tank body is constructed from high-density HDPE (high-density polyethylene) plastic, which exhibits excellent resistance to corrosion from automotive steering oil (compatible with mineral oil and synthetic hydraulic oil) and chemical aging. It can withstand a maximum working pressure of 0.8MPa without deformation, and the material’s low temperature resistance (-40℃) ensures no cracking in cold winter conditions. The tank’s outer surface is treated with an anti-UV coating, preventing color fading and material brittleness caused by long-term exposure to sunlight
Sealed & Pressure-Stabilized Design
The assembly is equipped with a high-quality rubber oil cap with a built-in pressure relief valve (opening pressure: 0.12-0.15MPa), which maintains stable internal pressure in the steering system. This prevents oil leakage caused by excessive pressure and avoids air ingress into the hydraulic circuit (a common cause of steering jitter). The oil inlet/outlet ports use double-seal O-rings (material: nitrile rubber) with excellent oil resistance and wear resistance, ensuring a tight seal even under long-term vibration (up to 50Hz) during vehicle operation
Easy Installation & Maintenance-Friendly Features
Designed for hassle-free installation, the assembly comes with pre-drilled mounting holes that align with the vehicle’s original brackets, allowing installation using standard M8 bolts and basic hand tools in 10-15 minutes. The transparent oil level window on the tank side enables quick visual inspection of oil volume and cleanliness without opening the cap. The filter element adopts a twist-lock design, which can be replaced in 2-3 minutes without disassembling the entire tank—greatly reducing maintenance time and labor costs for fleet operators
TECHNICAL SUPPORT
1. Accessories selection consultation
- Provide ** intelligent selection tools ** (such as parts matching query system), input the vehicle model VIN code or engine model to match the corresponding parts number, reducing the selection error rate.
The technical team is available online 7×12 hours to answer technical questions about accessories (such as material compatibility and installation processes).
2. Customized development support
We offer specialized R&D services for special market demands (such as heat dissipation accessories for high-temperature regions in the Middle East and dedicated suspension components for road conditions in Africa), and complete sample delivery within six weeks.
3. Training and Technical materials
Provide remote/on-site training for the customer's after-sales team (such as diagnosis of electrical control accessories and DPF regeneration operation), along with multilingual versions of the "Accessories Installation Manual" and "Troubleshooting Guide".
4. Quality Traceability and Improvement
Through the QR code traceability system (one product, one code), track the production batch of accessories and the source of raw materials, respond quickly to quality complaints and initiate improvement processes.
AFTER-SALES AND LOGISTICS SUPPORT
After-sales service
Quality Assurance Policy
-The warranty period for original factory parts is 12 months (counting from the date of signature for receipt), covering material defects, process issues, and man-made damage.
- Provide "Localized Express repair Service" : Cooperate with third-party repair networks in markets such as Southeast Asia and the Middle East, and deliver emergency parts to designated repair points within 4 hours.
Return and Exchange Process
-The customer is required to submit the test report (such as a third-party appraisal) within the warranty period. After confirmation by Dongfeng, a reissue or refund will be arranged within 5 working days.
Logistics support
Warehouse Layout
-Five major regional accessory centers have been established globally (Southeast Asia, the Middle East, Africa, South America, and Europe) to achieve "next-day delivery" for mainstream accessories (covering customers within the regions).
Emergency Logistics Plan
-Emergency parts can be directly delivered within 48 hours via the "Dongfeng Exclusive Aviation Special Line" (such as engine ECU, brake valves and other key components).
Packaging Optimization
-Use shockproof and moisture-proof packaging (such as honeycomb cartons + pearl cotton), and reinforce fragile parts (such as glass, sensors), keeping the damage rate within 0.5%.
