Dongfeng GX Right rear combination lamp 3773020-T62H0

Equipped with a high-transmittance PC (polycarbonate) lens treated with anti-scratch and anti-glare coatings, the lamp achieves 92% light transmittance, minimizing light loss and ensuring uniform illumination. The brake light uses a high-power LED bulb (1600 lumens) with a response time of ≤0.04s—4x faster than traditional halogen bulbs—providing earlier warning to following vehicles and reducing rear-end collision risks. The reverse light adopts a wide-beam reflector design, covering a 130° horizontal range and 6-9m distance behind the vehicle, significantly improving visibility for reverse parking or low-speed maneuvering

The lamp housing is crafted from high-strength ABS plastic with a UV-stabilized coating, preventing color fading, cracking, or deformation under extreme temperatures (-35℃ to 88℃) and long-term sunlight exposure. The lens and housing are sealed with a dual-layer silicone gasket, achieving an IP68 waterproof rating—resistant to high-pressure water jets (80℃, 80-100 bar) and dust intrusion, ensuring normal operation in heavy rain, snow, or dusty conditions. Additionally, the housing’s edge is reinforced with a shock-absorbing rubber buffer, reducing damage from small stones, road debris, or minor rear-end collisions

Engineered to strict original equipment (OE) specifications, the combination lamp features precision-machined mounting brackets and a plug-and-play wiring connector that perfectly aligns with the Dongfeng GX’s rear body panel and factory electrical system. No modifications to the vehicle’s body, bumper, or wiring harness are required during installation; it can be directly swapped with the original lamp, ensuring consistent exterior appearance, alignment, and aerodynamic performance. The lamp’s dimensions (265mm×185mm×115mm) and weight (1.2kg) are identical to the OE part, preserving the vehicle’s original design integrity

The 3773020-T62H0 combination lamp meets international ECE R7 (rear lamp safety), ECE R13 (brake light safety), and Chinese GB 4785 (automotive lighting and light-signaling devices standard) requirements. All bulbs and electrical components undergo 1500-hour aging tests and 600-cycle temperature shock tests to ensure stable performance in extreme environments (e.g., high humidity, rapid temperature changes). The LED bulbs also feature built-in overcurrent protection, preventing circuit damage from voltage fluctuations. Furthermore, the lamp’s light intensity and beam pattern are factory-calibrated, eliminating post-installation adjustment and ensuring compliance with global road safety regulations
