Dongfeng GX Full LCD instrument panel assembly 3801210-C6200

The part number 3801210-C6200 is a unique official identifier authorized by Dongfeng, distinguishing this genuine full LCD instrument panel from counterfeit or incompatible alternatives. By inputting this number into Dongfeng’s official parts database, users can access key details: production batch, manufacturing date, quality inspection records (e.g., display clarity and system stability tests), and authorized supply channels—enabling full lifecycle traceability. This traceability is critical for functionality: if the panel malfunctions (e.g., screen flicker), the part number helps track production defects to ensure timely replacement. For workshops, it simplifies inventory management and procurement, avoiding wrong purchases. The number is clearly laser-etched on the panel’s back housing, remaining legible even after long-term use, facilitating easy authenticity verification

As a core cockpit information component, this full LCD panel features a 12.3-inch high-definition (1920×720 resolution) IPS screen with 1000 nits brightness, ensuring clear visibility even under direct sunlight (no glare or washout). It supports multiple display modes: classic (speedometer + tachometer), sport (dynamic speed graph + torque display), and eco (fuel consumption + driving efficiency). The panel real-time displays critical vehicle data: speed, RPM, battery voltage, coolant temperature, and ADAS (Advanced Driver Assistance Systems) alerts (e.g., lane departure, collision warning). It also integrates with the infotainment system to show navigation maps, music playlists, and incoming calls. The screen uses a 60Hz refresh rate to avoid lag, and the backlight adjustment is automatic (sensing ambient light) for comfortable viewing day and night

To withstand the cockpit environment (temperature fluctuations, vibration), this LCD panel assembly adopts a robust design and reliable hardware configuration. The outer casing is made of flame-retardant ABS plastic (meeting UL94 V-0 standard) that resists impact and high temperatures (operating temperature: -30°C to 70°C). The internal circuit board uses industrial-grade chips (e.g., ARM Cortex-A53 processor) with stable performance, supporting continuous operation without overheating. The screen is covered with a scratch-resistant Gorilla Glass (hardness ≥6H), preventing damage from accidental scratches. It also has an anti-electromagnetic interference (EMI) shield that avoids signal disruption from the vehicle’s electrical system. Every unit undergoes 100% quality testing: 1000-hour high-temperature operation test, vibration test (10-500Hz), and screen durability test, ensuring a service life of 8-10 years

Designed for efficient replacement, this full LCD instrument panel features plug-and-play installation that requires no complex modifications. It uses the original Dongfeng GX wiring harness connector—users only need to disconnect the old panel, plug in the new one, and fasten it to the dashboard with 4 self-tapping screws (using a Phillips screwdriver). No soldering or software programming is needed, as the panel automatically synchronizes with the vehicle’s CAN bus system after power-on (recognizing vehicle parameters and enabling all functions). A bilingual (English/Chinese) installation manual is included, providing step-by-step instructions and safety tips (e.g., disconnecting the battery before installation). Even novice maintenance personnel can complete replacement in 30-40 minutes. Unlike aftermarket panels that require third-party software adaptation, this assembly ensures full compatibility with the vehicle’s original systems, maintaining all factory-set functions
