Electrical system
The combination instrument assembly (Part No. 3804050-C5100) is exclusively customized for Dongfeng KR series heavy-duty trucks and commercial vehicles, perfectly matching the vehicle’s electrical system and dashboard mounting structure. It is a direct OEM replacement part, eliminating the need for complex wiring modifications or bracket adjustments, ensuring seamless integration with the vehicle’s original control unit to maintain consistent operational logic
Product Attributes
Warranty: 1 YEARS ,Part name: Combination instrument assembly 3804050-C5100
PRODUCT DESCRIPTION
Comprehensive Multi-Information Display
Equipped with a high-definition LCD screen and LED backlit analog gauges, the instrument provides real-time monitoring of key vehicle parameters, including engine speed (0-3000 RPM), vehicle speed (0-120 km/h), fuel level (0-100%), engine coolant temperature (40-120℃), oil pressure (0-10 bar), and battery voltage (12-24V). Additionally, it features warning indicators for abnormal conditions such as low oil pressure, high coolant temperature, and brake system faults, delivering clear and timely alerts to the driver
High Precision & Stable Data Transmission
Adopting advanced CAN bus communication technology, the instrument achieves fast and accurate data acquisition from the vehicle’s ECU (Engine Control Unit) and other sensors, with a data update frequency of 10 times per second to ensure real-time synchronization of parameters. The analog gauges use high-precision stepper motors, with an error margin of less than ±1% for speed and RPM measurements, providing reliable data support for safe driving and vehicle maintenance
Durable & Environmentally Resistant Construction
The instrument housing is made of flame-retardant ABS plastic with a scratch-resistant surface coating, capable of withstanding impact forces up to 50N without structural damage. It meets IP6K5 protection standards, effectively resisting dust intrusion, water splashes, and high humidity (relative humidity 10%-95%, non-condensing). The internal electronic components are designed to operate stably in a wide temperature range of -40℃ to 85℃, adapting to harsh working environments such as cold plateaus and high-temperature deserts
User-Friendly Operation & Easy Maintenance
The instrument panel is designed with ergonomic button layouts, including independent buttons for switching display modes (trip A/B, average fuel consumption, total mileage) and adjusting backlight brightness (5 levels), allowing the driver to operate without distracting from driving. The detachable front cover simplifies maintenance—if the LCD screen or LED bulbs need replacement, the cover can be removed with standard tools in 2-3 minutes, reducing maintenance time and costs for fleet operators
TECHNICAL SUPPORT
1. Accessories selection consultation
- Provide ** intelligent selection tools ** (such as parts matching query system), input the vehicle model VIN code or engine model to match the corresponding parts number, reducing the selection error rate.
The technical team is available online 7×12 hours to answer technical questions about accessories (such as material compatibility and installation processes).
2. Customized development support
We offer specialized R&D services for special market demands (such as heat dissipation accessories for high-temperature regions in the Middle East and dedicated suspension components for road conditions in Africa), and complete sample delivery within six weeks.
3. Training and Technical materials
Provide remote/on-site training for the customer's after-sales team (such as diagnosis of electrical control accessories and DPF regeneration operation), along with multilingual versions of the "Accessories Installation Manual" and "Troubleshooting Guide".
4. Quality Traceability and Improvement
Through the QR code traceability system (one product, one code), track the production batch of accessories and the source of raw materials, respond quickly to quality complaints and initiate improvement processes.
AFTER-SALES AND LOGISTICS SUPPORT
After-sales service
Quality Assurance Policy
-The warranty period for original factory parts is 12 months (counting from the date of signature for receipt), covering material defects, process issues, and man-made damage.
- Provide "Localized Express repair Service" : Cooperate with third-party repair networks in markets such as Southeast Asia and the Middle East, and deliver emergency parts to designated repair points within 4 hours.
Return and Exchange Process
-The customer is required to submit the test report (such as a third-party appraisal) within the warranty period. After confirmation by Dongfeng, a reissue or refund will be arranged within 5 working days.
Logistics support
Warehouse Layout
-Five major regional accessory centers have been established globally (Southeast Asia, the Middle East, Africa, South America, and Europe) to achieve "next-day delivery" for mainstream accessories (covering customers within the regions).
Emergency Logistics Plan
-Emergency parts can be directly delivered within 48 hours via the "Dongfeng Exclusive Aviation Special Line" (such as engine ECU, brake valves and other key components).
Packaging Optimization
-Use shockproof and moisture-proof packaging (such as honeycomb cartons + pearl cotton), and reinforce fragile parts (such as glass, sensors), keeping the damage rate within 0.5%.
