Electrical system
The Dongfeng VR Upper Control Unit Assembly (Part No.: 7916010-C5100) serves as the central command hub for the vehicle’s electronic control system, specifically engineered to manage and coordinate critical functions including engine operation parameters, transmission shifting logic, and vehicle dynamic stability controls. It integrates multi-channel sensor inputs (e.g., speed, temperature, pressure) and executes real-time data processing to optimize performance, ensuring seamless communication between the vehicle’s powertrain, chassis, and auxiliary systems. Designed with a modular architecture, this unit supports easy integration with Dongfeng VR’s proprietary vehicle control software, enabling flexible configuration for different commercial vehicle applications (e.g., heavy-duty trucks, buses)
Product Attributes
Warranty: 1 YEARS ,Part name: Upper control unit assembly 7916010-C5100
PRODUCT DESCRIPTION
Vehicle Compatibility & OE Standards
Exclusively developed as an Original Equipment (OE) replacement part for Dongfeng VR series commercial vehicles, this upper control unit assembly (7916010-C5100) adheres to strict Dongfeng engineering specifications and quality standards. It is fully compatible with Dongfeng VR models equipped with Euro VI emission-compliant engines and automated manual transmissions (AMTs), ensuring perfect fitment without the need for modification to the vehicle’s existing wiring harness or mounting brackets. Each unit undergoes factory pre-calibration to match the specific vehicle VIN (Vehicle Identification Number) parameters, guaranteeing immediate functionality and consistent performance upon installation
Durability & Environmental Resilience
Constructed with high-grade industrial materials, the Dongfeng VR Upper Control Unit Assembly (7916010-C5100) is built to withstand harsh operating environments common in commercial vehicle use. The outer housing features a IP6K9K-rated protective enclosure (dust-tight and resistant to high-pressure, high-temperature water jets), preventing damage from moisture, dust, and road debris. Internal components are coated with anti-corrosion materials, and the unit is tested to endure extreme temperature fluctuations (-40°C to +85°C) and vibration levels (up to 20G acceleration), ensuring reliable operation over a service life of 500,000+ kilometers under typical heavy-duty driving conditions
Performance Optimization & Safety Features
This upper control unit assembly is programmed to enhance both vehicle efficiency and safety. It dynamically adjusts fuel injection timing and engine torque output based on load conditions, reducing fuel consumption by up to 5% compared to older control unit models while maintaining maximum power delivery. Additionally, it integrates advanced safety protocols, including over-speed protection, engine overheat shutdown, and fault diagnosis for critical systems (e.g., brake hydraulics, ABS). The unit stores real-time diagnostic trouble codes (DTCs) and transmits data via CAN bus to the vehicle’s instrument cluster, enabling drivers and technicians to quickly identify and resolve issues, minimizing downtime and improving overall operational safety
Technical Specifications & Installation Convenience
The Dongfeng VR Upper Control Unit Assembly (7916010-C5100) features a compact design with dimensions of 185mm (L) × 120mm (W) × 85mm (H) and a weight of 1.2kg, allowing for easy installation in the vehicle’s dedicated electronic control compartment. It operates on a 24V DC power supply (compatible with Dongfeng VR’s standard electrical system) and has a maximum operating current of 15A. The unit is equipped with a 32-pin waterproof connector that uses gold-plated terminals to ensure low electrical resistance and stable signal transmission. For maintenance, it supports firmware updates via a standard OBD-II port, enabling technicians to install software upgrades without disassembling the unit, further reducing service time and costs
TECHNICAL SUPPORT
1. Accessories selection consultation
- Provide ** intelligent selection tools ** (such as parts matching query system), input the vehicle model VIN code or engine model to match the corresponding parts number, reducing the selection error rate.
The technical team is available online 7×12 hours to answer technical questions about accessories (such as material compatibility and installation processes).
2. Customized development support
We offer specialized R&D services for special market demands (such as heat dissipation accessories for high-temperature regions in the Middle East and dedicated suspension components for road conditions in Africa), and complete sample delivery within six weeks.
3. Training and Technical materials
Provide remote/on-site training for the customer's after-sales team (such as diagnosis of electrical control accessories and DPF regeneration operation), along with multilingual versions of the "Accessories Installation Manual" and "Troubleshooting Guide".
4. Quality Traceability and Improvement
Through the QR code traceability system (one product, one code), track the production batch of accessories and the source of raw materials, respond quickly to quality complaints and initiate improvement processes.
AFTER-SALES AND LOGISTICS SUPPORT
After-sales service
Quality Assurance Policy
-The warranty period for original factory parts is 12 months (counting from the date of signature for receipt), covering material defects, process issues, and man-made damage.
- Provide "Localized Express repair Service" : Cooperate with third-party repair networks in markets such as Southeast Asia and the Middle East, and deliver emergency parts to designated repair points within 4 hours.
Return and Exchange Process
-The customer is required to submit the test report (such as a third-party appraisal) within the warranty period. After confirmation by Dongfeng, a reissue or refund will be arranged within 5 working days.
Logistics support
Warehouse Layout
-Five major regional accessory centers have been established globally (Southeast Asia, the Middle East, Africa, South America, and Europe) to achieve "next-day delivery" for mainstream accessories (covering customers within the regions).
Emergency Logistics Plan
-Emergency parts can be directly delivered within 48 hours via the "Dongfeng Exclusive Aviation Special Line" (such as engine ECU, brake valves and other key components).
Packaging Optimization
-Use shockproof and moisture-proof packaging (such as honeycomb cartons + pearl cotton), and reinforce fragile parts (such as glass, sensors), keeping the damage rate within 0.5%.
