Dongfeng KL truck parts Power socket with bracket 3723416-C3100

Built to meet the diverse power needs of modern truck drivers, this socket delivers stable high-power output for various on-board devices. With a 20A rated current and 240W maximum power, it can simultaneously support high-consumption equipment like 12V portable refrigerators (60W), dash cams (10W), GPS navigators (5W), and mobile phone fast chargers (25W)—critical for long-haul drivers relying on multiple devices. The socket features a standard SAE J563 interface with 4 copper contact points, ensuring low contact resistance (≤0.03Ω) and minimal voltage drop (≤0.2V) even under full load. A built-in power stabilization module filters voltage fluctuations (common in truck electrical systems) to protect sensitive devices like laptops from damage, ensuring consistent performance for both daily and emergency use

Engineered with an integrated bracket for superior structural stability, the 3723416-C3100 stands out from ordinary socket components. The bracket is made of cold-rolled steel (Q235 grade) with a 1.5mm thickness, achieving a tensile strength of 370MPa and resisting deformation from cab vibration (10-500Hz) or accidental impacts. It wraps 180° around the socket housing, distributing stress evenly and preventing the socket from loosening—an issue common with bracket-less alternatives that cause device disconnection. The bracket’s surface undergoes galvanization and powder coating (80μm thickness), passing 1500-hour neutral salt spray testing (ASTM B117) with no rust. This integrated design not only simplifies installation but also extends the socket’s service life by 50% compared to separate socket-and-bracket setups

Optimized for maximum safety in truck cabs, the power socket integrates multiple protective mechanisms to prevent electrical hazards. A built-in thermal circuit breaker (20A rating) automatically trips to cut off power if current exceeds the safe limit, avoiding wire overheating and fire risks caused by short circuits or overloaded devices. The socket housing is made of flame-retardant PBT plastic (UL94 V-0 grade) that resists ignition and maintains structural integrity at temperatures up to 230℃. A silicone rubber seal (IP65 protection) around the socket opening blocks dust and water splashes, while the 3-pin connector uses HNBR rubber gaskets to prevent moisture ingress. An insulation resistance of ≥100MΩ (DC 500V) ensures no current leakage, protecting drivers from electric shock and safeguarding the truck’s electrical system

This power socket with bracket is designed for driver convenience and long-term cost savings for Dongfeng KL operators. The socket features a LED power indicator (blue) that clearly shows whether it’s energized, helping drivers avoid device charging failures due to power issues. The integrated bracket’s snap-in mounting allows a single technician to complete installation in 20 minutes—40% faster than installing separate sockets and brackets. The OE-compatible design ensures perfect integration with the cab’s electrical system, avoiding the voltage instability of aftermarket sockets that damage expensive devices (e.g., a 12V refrigerator repair costs $300+). With a service life of ≥250,000km—three times that of non-OE alternatives—it reduces replacement frequency. Backed by a 1-year/150,000km Dongfeng warranty, it provides reliable power support and predictable maintenance expenses, enhancing driver satisfaction and fleet efficiency
