Dongfeng KL truck parts Multi functional display screen assembly 7915110-C3300

Built for reliable information display in diverse driving environments, this assembly features a high-performance IPS display with exceptional visibility. The 10.25-inch screen boasts 1280×720 HD resolution, 500 nits brightness, and 178° full-viewing-angle, ensuring clear readability even under direct sunlight (reducing glare by 70% via anti-reflective coating) or in dim night conditions (with adjustable brightness 0-100%). The IPS panel delivers consistent color accuracy and contrast, making critical data—such as speed, fuel consumption, and fault codes—easily distinguishable. A scratch-resistant Gorilla Glass cover (hardness ≥7H) protects the screen from accidental scratches by tools or cleaning cloths, maintaining display clarity for 300,000km of operation. The screen responds to touch inputs in ≤100ms, ensuring smooth operation even with work gloves

Engineered as the central hub for cab information and controls, the 7915110-C3300 display integrates multiple core functions to optimize driver efficiency. It supports five key modules: 1) Vehicle status monitoring (real-time data on engine speed, coolant temperature, and tire pressure); 2) Navigation (GPS/Beidou integration with route planning and traffic alerts); 3) Multimedia (audio playback, Bluetooth hands-free calling); 4) Rearview camera feed (split-screen display with vehicle data); 5) Fault diagnosis (displaying DTC codes and guiding basic troubleshooting). The intuitive UI is customized for truck drivers, with large icons and one-touch access to frequently used functions, reducing eye and hand movement. It also supports firmware updates via USB or 4G, ensuring compatibility with future system upgrades

Optimized to endure the harsh operating environment of truck cabs, the display assembly features comprehensive protective designs. The housing is made of flame-retardant ABS+PC alloy (UL94 V-0 grade) with a sealed structure, achieving IP54 protection rating—resisting dust ingress and splashing water from cleaning or condensation. The internal circuit board uses high-temperature-resistant components, enabling stable operation in temperatures ranging from -30℃ to 70℃, adapting to frigid winters and sun-exposed dashboards. It passes 2000-hour vibration testing (10-500Hz) without display flickering or component failure, enduring road bumps and engine vibration. The connector is equipped with a rubber seal to prevent corrosion, ensuring reliable data transmission even in humid coastal regions

This multi-functional display assembly is designed for efficient installation and long-term cost savings for Dongfeng KL operators. The pre-assembled structure (screen + bracket + wiring harness) allows a single technician to complete replacement in 60 minutes using only basic tools—no specialized programming required, as it auto-syncs with the truck’s CAN bus system. The OE-compatible design eliminates compatibility issues common with aftermarket displays, which often cause system crashes or data loss (repair costs up to $1,000). By centralizing controls, it reduces driver distraction and improves operational efficiency, lowering the risk of route errors or missed alerts (costing $500+ per incident). Backed by a 2-year/200,000km Dongfeng warranty, it provides reliable information management and predictable maintenance expenses for fleet operations
