Cummins engine spare parts air compressor C5580010 in stocked

Built to deliver consistent air supply for truck air brakes, suspension systems, and auxiliary equipment, this air compressor boasts exceptional output efficiency. It features a dual-cylinder, reciprocating piston design that generates a rated air flow of 420 L/min at 1200rpm—30% higher than single-cylinder alternatives—easily meeting the demands of multi-circuit air systems in heavy trucks. The maximum working pressure is 1.0MPa, with an automatic pressure relief valve that prevents over-pressurization. Equipped with a high-efficiency intake filter, it reduces air impurities by 98%, ensuring clean air supply to extend the lifespan of air dryers and brake components. Its rapid inflation capability cuts air system recovery time by 25% after heavy brake use, enhancing vehicle operational safety

Engineered for the rigorous operating conditions of commercial vehicles, the C5580010 air compressor features a heavy-duty build that ensures extended service life. The cylinder block is made of nodular cast iron (GG40) with a honed cylinder bore (Ra ≤0.2μm), reducing piston wear and oil consumption. Pistons and connecting rods use forged aluminum alloy (6061-T6) for lightweight strength, while the crankshaft is heat-treated 42CrMo steel for fatigue resistance. It undergoes 100-hour continuous operation testing at 1800rpm without performance degradation, and its service life exceeds 250,000km—matching the engine’s durability. The sealed bearing design eliminates external lubrication needs, reducing maintenance workload for fleet managers

Optimized for fuel efficiency, the air compressor adopts a low-friction design that minimizes power draw from the engine. Its advanced valve train (double overhead camshafts) reduces mechanical losses by 15% compared to traditional designs, translating to a 2-3% improvement in engine fuel economy for long-haul trucks. The compressor is compatible with Cummins’ selective catalytic reduction (SCR) and diesel particulate filter (DPF) systems, meeting Euro VI and China National VI emission standards. It uses low-viscosity, eco-friendly lubricating oil (SAE 10W-30) that reduces carbon deposits and waste oil disposal costs. For in-stock units, pre-lubrication ensures immediate startup without dry friction, protecting internal components from initial wear

As a in-stock, factory-tested component, the C5580010 air compressor offers hassle-free installation and guaranteed performance. It comes with all necessary mounting hardware (bolts, gaskets, and pulley) and a 12-pin waterproof connector that plugs directly into the engine wiring harness—two technicians can complete replacement in 90 minutes, 40% faster than non-OE units. Each in-stock unit undergoes 20+ quality checks, including air tightness (leak rate ≤0.5 L/min at 1.0MPa), pressure stability, and noise level (≤75dB at 1m). Backed by a 1-year/100,000km warranty, it provides peace of mind for fleet operations. With centralized stock in major logistics hubs, it supports same-day or next-day delivery to minimize vehicle downtime, making it an ideal choice for urgent maintenance needs
