Dongfeng xinjiang truck parts Right radiator bracket assembly 1302045-T5KF01Y

Built to securely anchor the radiator (weight up to 45kg) and withstand dynamic forces during driving, this bracket assembly delivers exceptional fixing performance. It is fabricated from Q235 carbon steel (6mm thick for the main body, 8mm thick for support arms) with a tensile strength of ≥375MPa, enabling it to resist vertical and lateral vibrations (5-2000Hz, compliant with ISO 16750-3) without deformation. The radiator attachment points feature rubber cushion pads (EPDM material, 5mm thick) that absorb shock and prevent metal-to-metal contact—reducing radiator core damage from road and extending its service life by 25%. Unlike plastic brackets (common in light vehicles), this steel structure maintains clamping force even under extreme temperatures (-40℃ to 120℃), ensuring the radiator remains securely positioned during heavy-haul or off-road operations

Designed to shield the radiator from front-end debris and minor collisions, the bracket assembly integrates a reinforced impact-deflection structure. The outer edge of the bracket extends 30mm beyond the radiator’s right side, forming a protective barrier against rocks, gravel, or road obstacles. The support arms are engineered with a curved profile (radius: 80mm) that deforms elastically under low-impact forces (≤300N), redirecting energy away from the radiator core and preventing punctures or fin damage. Key stress points (between the bracket and chassis) are reinforced with triangular gussets (10mm thick), which distribute impact loads evenly across the frame and avoid localized cracking. In impact tests, the bracket reduces radiator damage by 60% compared to non-reinforced alternatives, minimizing repair costs for truck owners

Engineered to resist corrosion from road salt, rain, mud, and coolant leaks—major threats to front-end components—the bracket assembly features a comprehensive protective system. First, a zinc phosphate pretreatment layer (10μm) is applied to the steel surface to block rust at the substrate. Then, a high-temperature electrostatic powder coating (90μm) with epoxy-polyester composite is baked on, forming a scratch-resistant, waterproof barrier that resists peeling even after prolonged exposure to UV radiation or coolant spills. Finally, a clear chromate passivation layer enhances coating adhesion and chemical resistance. This system passes 1000-hour salt spray testing (per ASTM B117) with no red rust, ensuring durability for over 8 years in coastal areas, snowy regions, or industrial zones with high pollution. All mounting holes are pre-coated with anti-seize compound, preventing thread rust and enabling easy disassembly during radiator maintenance

Designed for efficient installation on Dongfeng Xinjiang trucks, the bracket assembly undergoes CNC cutting, drilling, and bending to achieve strict dimensional accuracy (length/width tolerance: ±0.3mm, hole position tolerance: ±0.1mm). The package includes 5 M10×25 galvanized bolts (for radiator connection) and 4 M12×35 grade 8.8 high-strength bolts (for chassis attachment)—matching the factory hardware specifications. Installation steps are straightforward: align the bracket’s chassis holes with the front frame pre-drilled points, secure with M12 bolts (torque to 50-55N·m), attach the radiator to the bracket using M10 bolts (torque to 25-30N·m), and verify clearance with adjacent components. No specialized tools are required, and a professional technician can complete the process in 35 minutes or less. The bracket also includes engraved alignment marks (“TOP” and “RIGHT”) to prevent incorrect installation, ensuring the radiator is positioned for optimal airflow on the first attempt—reducing labor costs and minimizing truck downtime
