Body system
This wiper motor assembly (Part No.: 3741010-C6100) is exclusively engineered for Dongfeng GX vehicles, strictly adhering to the original factory’s mechanical dimensions and electrical interface standards. It perfectly matches the wiper linkage mounting points and vehicle electrical system connectors, enabling direct replacement without drilling, wiring modifications, or adapter installation. This ensures seamless integration with the vehicle’s original wiper system, maintaining factory-level operating accuracy
Product Attributes
Warranty: 1 YEARS ,Part name: Wiper motor assembly 3741010-C6100
PRODUCT DESCRIPTION
High-Torque & Energy-Saving Motor Performance
Equipped with a high-efficiency permanent magnet DC motor, the assembly delivers a stable torque of 8-12 N·m (depending on specific vehicle configuration), ensuring smooth and powerful wiper operation even under heavy rain, snow, or ice accumulation. The motor adopts an energy-saving design with a working current of only 3-5A (at 12V), which reduces power consumption compared to ordinary aftermarket motors. It also supports multi-speed adjustment (low/high speed, intermittent mode) consistent with the original vehicle’s control logic, meeting diverse weather adaptation needs
Durable Sealed Structure Design
The motor housing is made of high-impact PA6+GF30 composite material, which resists deformation from low-temperature (-40°C) brittleness and high-temperature (80°C) aging. The assembly features a full-sealed structure: all rotating shafts and wire outlets are sealed with oil-resistant nitrile rubber gaskets and heat-shrinkable waterproof sleeves, effectively preventing water, dust, and road salt from entering the internal components. This design avoids motor short circuits, bearing rust, or brush wear caused by environmental factors, extending the service life
Noise-Reduction & Vibration-Damping Optimization
The motor is integrated with a precision gearbox with hardened steel gears (surface hardness up to HRC55) and a graphite copper sleeve bearing, which minimizes mechanical friction noise—operating noise is controlled below 55dB (measured at 1m distance), far lower than the industry average of 65dB. Additionally, the mounting bracket is equipped with rubber damping pads that absorb vibration during motor operation, preventing resonance with the vehicle body and ensuring quiet and comfortable driving
OEM-Grade Quality Testing & Certification
Manufactured in accordance with OEM quality standards, the assembly undergoes rigorous testing procedures: 1000-hour continuous operation test (simulating long-term use), 500-cycle high-low temperature shock test (-40°C to 80°C), 200-hour salt spray test (for corrosion resistance), and 100,000-cycle on/off durability test. It complies with international IEC 60034-1 motor standards and domestic GB/T 13384 automotive electrical equipment standards, ensuring reliable performance. The average service life of the motor reaches 300,000 km (or 5 years), reducing the frequency of replacement and maintenance costs
TECHNICAL SUPPORT
1. Accessories selection consultation
- Provide ** intelligent selection tools ** (such as parts matching query system), input the vehicle model VIN code or engine model to match the corresponding parts number, reducing the selection error rate.
The technical team is available online 7×12 hours to answer technical questions about accessories (such as material compatibility and installation processes).
2. Customized development support
We offer specialized R&D services for special market demands (such as heat dissipation accessories for high-temperature regions in the Middle East and dedicated suspension components for road conditions in Africa), and complete sample delivery within six weeks.
3. Training and Technical materials
Provide remote/on-site training for the customer's after-sales team (such as diagnosis of electrical control accessories and DPF regeneration operation), along with multilingual versions of the "Accessories Installation Manual" and "Troubleshooting Guide".
4. Quality Traceability and Improvement
Through the QR code traceability system (one product, one code), track the production batch of accessories and the source of raw materials, respond quickly to quality complaints and initiate improvement processes.
AFTER-SALES AND LOGISTICS SUPPORT
After-sales service
Quality Assurance Policy
-The warranty period for original factory parts is 12 months (counting from the date of signature for receipt), covering material defects, process issues, and man-made damage.
- Provide "Localized Express repair Service" : Cooperate with third-party repair networks in markets such as Southeast Asia and the Middle East, and deliver emergency parts to designated repair points within 4 hours.
Return and Exchange Process
-The customer is required to submit the test report (such as a third-party appraisal) within the warranty period. After confirmation by Dongfeng, a reissue or refund will be arranged within 5 working days.
Logistics support
Warehouse Layout
-Five major regional accessory centers have been established globally (Southeast Asia, the Middle East, Africa, South America, and Europe) to achieve "next-day delivery" for mainstream accessories (covering customers within the regions).
Emergency Logistics Plan
-Emergency parts can be directly delivered within 48 hours via the "Dongfeng Exclusive Aviation Special Line" (such as engine ECU, brake valves and other key components).
Packaging Optimization
-Use shockproof and moisture-proof packaging (such as honeycomb cartons + pearl cotton), and reinforce fragile parts (such as glass, sensors), keeping the damage rate within 0.5%.
