Dongfeng KR truck parts Interior rearview mirror assembly 8201050-C5100

The mirror features high-transparency float glass with a light transmittance of 92%—delivering distortion-free rearview visibility even in low-light conditions (e.g., dawn, dusk). The glass is coated with a multi-layer anti-glare film that reduces glare from headlights of following vehicles by 65%, preventing driver eye fatigue during night driving. Unlike standard uncoated mirrors that cause temporary blindness from bright lights, this anti-glare design maintains clear visibility while softening harsh light. The glass is also treated with a water-repellent coating that sheds condensation and light rain, ensuring unobstructed rearview in humid or rainy weather. Additionally, the glass is 2.1mm thick (impact-resistant) to withstand minor vibrations without cracking, ensuring long-term clarity

Built to withstand the constant vibration of truck cabs and minor impacts (e.g., accidental contact with cargo), the mirror housing uses high-impact ABS plastic (UL94 V-0 flame-retardant rating) with a matte finish that resists scratches and fingerprints. The housing’s edges are rounded to prevent injury from sharp corners, and the internal mounting bracket is made of 2mm-thick cold-rolled steel (Q235 grade) that absorbs vibration—reducing mirror shake by 40% compared to plastic-only brackets. The mirror glass is bonded to the housing with high-strength automotive-grade adhesive that tolerates temperature extremes from -40°C (cold starts) to 85°C (cab heat) without peeling. Unlike flimsy plastic mirrors that crack or detach under vibration, this rugged design ensures the assembly remains intact and functional for 5+ years

Engineered to accommodate drivers of different heights and seating positions, the mirror offers flexible adjustment capabilities. The mounting bracket features a ball-and-socket joint that allows 360° horizontal rotation and 120° vertical tilt—enabling precise alignment to cover the entire rear window (no blind spots). The joint is equipped with a stainless steel spring that maintains tension, keeping the mirror in position even during rough driving (e.g., gravel roads). Unlike fixed or limited-adjustment mirrors that force drivers to compromise on visibility, this design lets each driver customize the angle for optimal rearview coverage. Additionally, the mirror housing has a built-in adjustment lever (on the side) that allows quick anti-glare mode activation—no need to manually reposition the entire mirror during night driving

Designed for hassle-free replacement by fleet technicians or DIY owners, the assembly simplifies installation and upkeep. It includes all necessary hardware: 2 OEM-matched stainless steel bolts, lock washers, and a foam gasket that reduces vibration transfer to the windshield. Installation takes 15–20 minutes: remove the old mirror by unscrewing the base bolts, clean the mounting surface, align the new mirror’s base with the windshield bracket, tighten the bolts to 18 N·m torque, and adjust the mirror angle. For maintenance, the ABS housing wipes clean with a damp cloth (resisting stains from dust or grease), and the anti-glare coating requires no special care. The mirror glass is replaceable separately (if cracked) without buying the entire assembly, reducing repair costs. Each unit undergoes vibration testing (10–2,000 Hz), impact testing, and visibility verification, backed by a 24-month warranty against defects (e.g., housing cracking, glass peeling, joint failure)
