Dongfeng Xinjiang truck parts Luminous emblem assembly 5000515-C43X701S

Equipped with a 5W high-efficiency LED light source (10pcs 0.5W SMD LEDs), the emblem delivers a uniform luminous flux of 450 lumens with a 6,500K cool white light—bright enough to be visible from 50 meters away at night while avoiding glare to oncoming vehicles. The LED chips are arranged in a brand-specific pattern (matching Dongfeng’s official emblem outline) and covered with a light-diffusing PC panel (transmittance ≥92%), ensuring the emblem’s shape remains clear and recognizable even in dark environments. A built-in light sensor automatically activates the luminous function when ambient light intensity is below 200 lux (e.g., dusk, night, or tunnels) and turns it off during the day—saving energy and extending LED lifespan (exceeding 60,000 hours, 12 times longer than traditional incandescent luminous components). This feature enhances the truck’s nighttime (recognition) for fleet management and improves safety in low-visibility conditions

Engineered to withstand Dongfeng Xinjiang trucks’ operating environments—including desert sandstorms, heavy snow, and temperature swings from -35°C to 45°C—the emblem assembly achieves an IP67 protection rating. The outer shell uses high-impact PC plastic (impact strength ≥60 kJ/m²) with a scratch-resistant coating (Mohs hardness ≥5H), resisting damage from flying stones or minor collisions. The LED circuit board is encapsulated in epoxy resin, preventing water and dust intrusion even during 30 minutes of 1m-deep water immersion. The wiring connector is sealed with a silicone gasket, blocking sand and moisture from entering the electrical system. Additionally, the shell’s surface is treated with an anti-UV coating that passes 3,000 hours of xenon lamp aging (≤3% color fade), ensuring the emblem retains its original luster and luminous performance in intense sunlight

Designed to avoid draining the truck’s battery, the emblem operates at a low power consumption of 5W (0.42A current at 12V), which is 60% lower than traditional luminous emblems (12W). A built-in overvoltage protector cuts off power when the electrical system voltage exceeds 16V (e.g., due to alternator faults), preventing damage to the LED circuit. Reverse polarity protection also prevents short circuits if the wiring is connected incorrectly during installation—avoiding electrical system damage to the truck. The emblem’s light sensor is calibrated to avoid false activation (e.g., from passing streetlights) and has a response time of ≤0.5 seconds, ensuring timely luminous activation/deactivation. These safety features meet ISO 16750 automotive electrical standards, ensuring reliable operation in the truck’s complex electrical environment (e.g., simultaneous use of headlights, GPS, and other accessories)

Designed for easy replacement by fleet technicians or DIY owners, the emblem simplifies installation with user-friendly features. The wiring harness includes a plug-and-play connector that matches the Dongfeng Xinjiang truck’s factory auxiliary power socket—no cutting, soldering, or adapter required—reducing wiring time by 70%. The emblem comes with 2 stainless steel M5×12mm bolts (rust-resistant for snowy or coastal regions) and lock washers, which can be tightened with a standard hex wrench in 10–15 minutes. A positioning template is included to align the emblem with the grille’s recess, ensuring accurate placement without measuring. Each unit undergoes 100% luminous performance testing, waterproof verification, and electrical safety checks, backed by a 24-month warranty against defects (e.g., LED failure, water leakage, shell cracking)
